FZXL-C (2 Right diagonal holes)
FZXL-C high performance clutch button
1, Dimension:63x57mm, 2 vertical holes with sunburst grooves;
2, Thickness: 4.0mm-4.8mm; Rivet holes: 9.4mm;
FZXL-C is a type of performance clutch has grooves on the surface areas. The auto clutch kit has this product can be used in wet clutch envirement of oil. We have three clutch button formula currently, one is our regular formula, smooth finish and medium property, another is the low wear formula with rough finish, the third one is a new formula, it's developed with the assistance of the oversea engineer, and this button is following Miba appearance and similar to its finish and property, it is supplied to our OE customers, due to its low cost and excellent property, it is very popular among our customers from South America and India.
| FRICWEL NO. | DESCRIPTION | DIMENSION (mm) |
WELLMAN | WELLMAN THICKNESS | MIBA | MIBA THICKNESS | ||
| INCH | MM | INCH | MM | |||||
| FYXL 140.360 | 2 Right diagonal holes | 63X57 | VTD-4R | 0.142 | 3.607 | BD 140.360R | 0.140 | 3.556 |
| FYXL 156.400 | VTD-5R | 0.157 | 3.988 | BD 156.400R | 0.156 | 3.962 | ||
| FYXL 173.440 | VTD-7R | 0.177 | 4.496 | BD 173.440R | 0.173 | 4.394 | ||
| FYXL 187.480 | VTD-8R | 0.189 | 4.801 | BD 187.480R | 0.187 | 4.750 | ||
